Germ Free Containers

Steam sterilizable, vacuum resistant aseptic containers provide the highest level of protection for aseptic applications. Aseptic stainless steel IBCs guarantee maximum hygiene for sensitive applications in the food and cosmetics and pharmaceutical industries. These containers are easy to clean and have an outstandingly long service life.

Application

• Fruit preparations
• Fruit concentrates
• Beverage ingredients
• Aromas and essences
• Liquid seasonings and sauces
• Mayonnaises
• Liquid egg products
• Cosmetics
• Pharmaceuticals

Tank Material

• Stainless steel 1.4301 / 1.4404 / 1.4571

Wall Thickness

• 1.5 to 2.5 mm for top section, shell and bottom section

Manhole

• DN 400 in the top section with bolted or bayonet ring cover

Transport Frame

• Profile frame or tube frame

Equipment

• Manhole cover with pressure relief valve ('TUV approved) and DN 6.5 or DN 12 CO2 valve.
• DN 50 threaded connectors with cap nuts (optional)

Approval

• CE Mark in accordance with Pressure Equipment Directive 97/23 according to AD 2000 S5, up to 2 bar operating pressure
• Complies with Regulation (EC) No. 1935/2004

Handling

• Can be transported and stacked using all usual forklift vehicles
• Steam sterilizable, vacuum resistant
• Easy to clean

Optional

• With heating or cooling shell
• Stirring device

DIMENSIONS
